SQL SERVER – DMV to Identify Incremental Statistics – Performance improvements in SQL Server 2014 – Part 3

This is the third part of the series Incremental Statistics. Here is the index of the complete series.


In earlier two parts we have seen what is incremental statistics and its simple example. In this blog post we will be discussing about DMV, which will list all the statistics which are enabled for Incremental Updates.

SELECT  OBJECT_NAME(sys.stats.OBJECT_ID) AS TableName,
sys.columns.name AS ColumnName,
sys.stats.name AS StatisticsName
FROM   sys.stats
INNER JOIN sys.stats_columns ON sys.stats.OBJECT_ID = sys.stats_columns.OBJECT_ID
AND sys.stats.stats_id = sys.stats_columns.stats_id
INNER JOIN sys.columns ON sys.stats.OBJECT_ID = sys.columns.OBJECT_ID
AND sys.stats_columns.column_id = sys.columns.column_id
WHERE   sys.stats.is_incremental = 1

If you run above script in the example displayed, in part 1 and part 2 you will get resultset as following.

When you execute the above script, it will list all the statistics in your database which are enabled for Incremental Update. The script is very simple and effective. If you have any further improved script, I request you to post in the comment section and I will post that on blog with due credit.

Reference: Pinal Dave (http://blog.sqlauthority.com)

About these ads

SQL SERVER – Simple Example of Incremental Statistics – Performance improvements in SQL Server 2014 – Part 2

This is the second part of the series Incremental Statistics. Here is the index of the complete series.


In part 1 we have understood what is incremental statistics and now in this second part we will see a simple example of incremental statistics. This blog post is heavily inspired from my friend Balmukund’s must read blog post. If you have partitioned table and lots of data, this feature can be specifically very useful.

Prerequisite

Here are two things you must know before you start with the demonstrations.

AdventureWorks – For the demonstration purpose I have installed AdventureWorks 2012 as an AdventureWorks 2014 in this demonstration.

Partitions – You should know how partition works with databases.

Setup Script

Here is the setup script for creating Partition Function, Scheme, and the Table. We will populate the table based on the SalesOrderDetails table from AdventureWorks.

-- Use Database
USE AdventureWorks2014
GO
-- Create Partition Function
CREATE PARTITION FUNCTION IncrStatFn (INT) AS RANGE LEFT FOR VALUES
(44000, 54000, 64000, 74000)
GO
-- Create Partition Scheme
CREATE PARTITION SCHEME IncrStatSch AS PARTITION [IncrStatFn] TO
([PRIMARY], [PRIMARY], [PRIMARY], [PRIMARY], [PRIMARY])
GO
-- Create Table Incremental_Statistics
CREATE TABLE [IncrStatTab](
[SalesOrderID] [int] NOT NULL,
[SalesOrderDetailID] [int] NOT NULL,
[CarrierTrackingNumber] [nvarchar](25) NULL,
[OrderQty] [smallint] NOT NULL,
[ProductID] [int] NOT NULL,
[SpecialOfferID] [int] NOT NULL,
[UnitPrice] [money] NOT NULL,
[UnitPriceDiscount] [money] NOT NULL,
[ModifiedDate] [datetime] NOT NULL)
ON IncrStatSch(SalesOrderID)
GO
-- Populate Table
INSERT INTO [IncrStatTab]([SalesOrderID], [SalesOrderDetailID],
[CarrierTrackingNumber], [OrderQty], [ProductID],
[SpecialOfferID], [UnitPrice],   [UnitPriceDiscount], [ModifiedDate])
SELECT     [SalesOrderID], [SalesOrderDetailID],
[CarrierTrackingNumber], [OrderQty], [ProductID],
[SpecialOfferID], [UnitPrice],   [UnitPriceDiscount], [ModifiedDate]
FROM       [Sales].[SalesOrderDetail]
WHERE      SalesOrderID < 54000
GO

Check Details

Now we will check details in the partition table IncrStatSch.

-- Check the partition
SELECT *
FROM sys.partitions
WHERE OBJECT_ID = OBJECT_ID('IncrStatTab')
GO

You will notice that only a few of the partition are filled up with data and remaining all the partitions are empty.

Now we will create statistics on the Table on the column SalesOrderID.

However, here we will keep adding one more keyword which is INCREMENTAL = ON. Please note this is the new keyword and feature added in SQL Server 2014. It did not exist in earlier versions.

-- Create Statistics
CREATE STATISTICS IncrStat
ON [IncrStatTab] (SalesOrderID)
WITH FULLSCAN, INCREMENTAL = ON
GO

Now we have successfully created statistics let us check the statistical histogram of the table.

Now let us once again populate the table with more data. This time the data are entered into a different partition than earlier populated partition.

-- Populate Table
INSERT INTO [IncrStatTab]([SalesOrderID], [SalesOrderDetailID],
[CarrierTrackingNumber], [OrderQty], [ProductID],
[SpecialOfferID], [UnitPrice],   [UnitPriceDiscount], [ModifiedDate])
SELECT     [SalesOrderID], [SalesOrderDetailID],
[CarrierTrackingNumber], [OrderQty], [ProductID],
[SpecialOfferID], [UnitPrice],   [UnitPriceDiscount], [ModifiedDate]
FROM       [Sales].[SalesOrderDetail]
WHERE      SalesOrderID > 54000
GO

Let us check the status of the partition once again with following script.

-- Check the partition
SELECT *
FROM sys.partitions
WHERE OBJECT_ID = OBJECT_ID('IncrStatTab')
GO

Statistics Update

Now here has the new feature come into action. Previously, if we have to update the statistics, we will have to FULLSCAN the entire table irrespective of which partition got the data.

However, in SQL Server 2014 we can just specify which partition we want to update in terms of Statistics. Here is the script for the same.

-- Update Statistics Manually
UPDATE STATISTICS IncrStatTab (IncrStat)
WITH RESAMPLE ON PARTITIONS(3, 4)
GO

Now let us check the statistics once again.

-- Show Statistics
DBCC SHOW_STATISTICS('IncrStatTab', IncrStat)
WITH HISTOGRAM
GO

Upon examining statistics histogram, you will notice that now the distribution has changed and there is way more rows in the histogram.

Summary

The new feature of Incremental Statistics is indeed a boon for the scenario where there are partitions and statistics needs to be updated frequently on the partitions. In earlier version to update statistics one has to do FULLSCAN on the entire table which was wasting too many resources. With the new feature in SQL Server 2014, now only those partitions which are significantly changed can be specified in the script to update statistics.

Cleanup

You can clean up the database by executing following scripts.

-- Clean up
DROP TABLE [IncrStatTab]
DROP PARTITION SCHEME [IncrStatSch]
DROP PARTITION FUNCTION [IncrStatFn]
GO

Reference: Pinal Dave (http://blog.sqlauthority.com)

SQL SERVER – What is Incremental Statistics? – Performance improvements in SQL Server 2014 – Part 1

This is the first part of the series Incremental Statistics. Here is the index of the complete series.


Statistics are considered one of the most important aspects of SQL Server Performance Tuning. You might have often heard the phrase, with related to performance tuning.

“Update Statistics before you take any other steps to tune performance”.

Honestly, I have said above statement many times and many times, I have personally updated statistics before I start to do any performance tuning exercise. You may agree or disagree to the point, but there is no denial that Statistics play an extremely vital role in the performance tuning.

SQL Server 2014 has a new feature called Incremental Statistics. I have been playing with this feature for quite a while and I find that very interesting. After spending some time with this feature, I decided to write about this subject over here.

New in SQL Server 2014 – Incremental Statistics

Well, it seems like lots of people wants to start using SQL Server 2014’s new feature of Incremetnal Statistics. However, let us understand what actually this feature does and how it can help. I will try to simplify this feature first before I start working on the demo code.

Code for all versions of SQL Server

Here is the code which you can execute on all versions of SQL Server and it will update the statistics of your table. The keyword which you should pay attention is WITH FULLSCAN. It will scan the entire table and build brand new statistics for you which your SQL Server Performance Tuning engine can use for better estimation of your execution plan.

UPDATE STATISTICS TableName(StatisticsName) WITH FULLSCAN

Who should learn about this? Why?

If you are using partitions in your database, you should consider about implementing this feature. Otherwise, this feature is pretty much not applicable to you. Well, if you are using single partition and your table data is in a single place, you still have to update your statistics the same way you have been doing.

If you are using multiple partitions, this may be a very useful feature for you. In most cases, users have multiple partitions because they have lots of data in their table. Each partition will have data which belongs to itself. Now it is very common that each partition are populated separately in SQL Server.

Real World Example

For example, if your table contains data which is related to sales, you will have plenty of entries in your table. It will be a good idea to divide the partition into multiple filegroups for example, you can divide this table into 3 semesters or 4 quarters or even 12 months. Let us assume that we have divided our table into 12 different partitions. Now for the month of January, our first partition will be populated and for the month of February our second partition will be populated. Now assume, that you have plenty of the data in your first and second partition. Now the month of March has just started and your third partition has started to populate. Due to some reason, if you want to update your statistics, what will you do?

In SQL Server 2012 and earlier version

You will just use the code of WITH FULLSCAN and update the entire table. That means even though you have only data in third partition you will still update the entire table. This will be VERY resource intensive process as you will be updating the statistics of the partition 1 and 2 where data has not changed at all.

In SQL Server 2014

You will just update the partition of Partition 3. There is a special syntax where you can now specify which partition you want to update now. The impact of this is that it is smartly merging the new data with old statistics and update the entire statistics without doing FULLSCAN of your entire table. This has a huge impact on performance.

Remember that the new feature in SQL Server 2014 does not change anything besides the capability to update a single partition. However, there is one feature which is indeed attractive. Previously, when table data were changed 20% at that time, statistics update were triggered. However, now the same threshold is applicable to a single partition. That means if your partition faces 20% data, change it will also trigger partition level statistics update which, when merged to your final statistics will give you better performance.

In summary

If you are not using a partition, this feature is not applicable to you.

If you are using a partition, this feature can be very helpful to you.

Tomorrow:

We will see working code of SQL Server 2014 Incremental Statistics.

Reference: Pinal Dave (http://blog.sqlauthority.com)

SQLAuthority News – Microsoft Whitepaper – Optimizing Your Query Plans with the SQL Server 2014 Cardinality Estimator

I have been reading this Whitepaper from a couple of days and I am yet not done reading it completely, but I think it is one of the best white papers I have read in the recent time. First of all, it is written by my friend and SQL Expert Joe Sack. If you know Joe, you know that he is blessed with the skill to make a complex subject very easy. There are very few experts can do this. Kudos to Joe for amazing white paper. This white paper is 43 pages long and over 10,000 words, but trust me, every single word is worth it. I am planning to complete this whitepaper this weekend.

Every new version of SQL Server gets new performance enhancement features. In SQL Server 2014 SQL Server Query Optimizer cardinality estimation process got a major overhaul. A new algorithm for the cardinality estimation now has improved accuracy, consistency and suitability of key areas within the cardinality estimation process. In simple words, it is going to improve performance of queries executed on SQL Server.

Here is the paragraph from the Whitepaper which describes what actually this white paper is going to include:

The SQL Server query optimization process seeks the most efficient processing strategy for executing queries across a wide variety of workloads. Achieving predictable query performance across online transaction processing (OLTP), relational data warehousing, and hybrid database schemas is inherently difficult. While many workloads will benefit from the new cardinality estimator changes, in some cases, workload performance may degrade without a specific tuning effort. In this paper, we will discuss the fundamentals of the SQL Server 2014 cardinality estimator changes. We will provide details on activating and deactivating the new cardinality estimator. We will also provide troubleshooting guidance for scenarios where query performance degrades as a direct result of cardinality estimate issues.

I personally believe there are so many new enhancements in SQL Server that sometimes, I feel foreign to this entire subject. I feel that SQL Server has moved ahead and I am still working with version n-1. However, when I come across white paper like this, I regain my own confidence as now I know I can depend on this white paper to learn what are the new features available. Later on I can go and implement this feature on production server and master the basics as well as advanced concepts.

Download the white paper from here.

Reference: Pinal Dave (http://blog.SQLAuthority.com)

SQL SERVER – Wrap on Series of Temporary Statistics

This is the final post in the series of the Temporary Statistics. I have previously written about this subject in a few posts. I have received quite a few questions about this series so I decided to include all the questions in this one blog post. Before you read this blog post, here are a few blog posts related to this subject.

Here are a few questions which I have received.

Question: Can I update the temporary statistics?
Answer: No, the user cannot create or update temporary statistics. SQL Server only can create or update temporary statistics. However, the user can drop the statistics with the help of DROP STATISTICS command.

Question: Is there any way the user can retain created temporary statistics permanently on SQL Server.
Answer: You can script out the temporary statistics and create them in the database with the steps described in the blog Scripting Statistics for Read-Only Database and Making it Permanent

Question: If database is read-only where are the temporary statistics are stored?
Answer: In the TempDB. Hence when you restart your SQL Server services, all the temporary statistics disappear.

Question: How can I know that if the statistics created is temporary or permanent?
Answer: You can run the SELECT query on sys.stats catalogue view and checkout the status of the index. If the is_temporary column is 1 for statistics it is temporary and if it is 0 it is permanent. Read more about that over here:  Statistics for Read-Only Database are in TempDB.

Reference: Pinal Dave (http://blog.sqlauthority.com)

SQL SERVER – Scripting Statistics for Read-Only Database and Making it Permanent

This is a follow up blog post to my earlier blog posts about statistics for Read-Only Database. Please read the following blog post in this series to get further idea about this subject:

One question which keeps on coming to my Inbox which was based on Read-Only Database and its best practices. Everybody wanted to know that they do understand that they have a read-only database and its statistics is in the TempDB. When TempDB is restarted it resets the statistics. If the user knows that next time they are going to execute the same kind of queries on the Read-Only database and it will once again create the similar statistics in TempDB, is there any way to create those statistics in the Read-Only database so next time when the server restarts (or service restarts) the statistics remains in the database instead of disappearing with TempDB?

In simple words the question is – How to move statistics from temporary status  to permanent status in the Read-Only database?

This is very interesting question and indeed a very easy one. First of all users should only move the statistics from the TempDB database to Read-Only database if he is confident that the same statistics are created multiple times and there is absolutely no change in the queries which are running against the Read-Only database. In my career I have seen Read-Only database which are refreshed daily, weekly or at intervals. If you have such database in that case, you should not think of moving the statistics from the TempDB till the database is in a consistent stage where data is not moving much.

Now if you have decided to move your database from TempDB to Read-Only database, here is a big problem – we can’t create statistics in Read-Only Database. A database must be in ReadWrite mode to create statistics. Hence, users will have to change the status of the database from Read-Only to ReadWrite and move the statistics from TempDB. Once the statistics are moved from TempDB, you can once again change the status of the database from ReadWrite to Read-Only. When statistics are generated based from your Read-Only database, it will additionally append suffix _scripted at the end of the statistic’s name. For example if your original statistic’s name is  MyStatisticsName_readonly_database_statistic, it will be automatically converted to MyStatisticsName_readonly_database_statistic_scripted.

Here is a summary of how we can do the same.

Step 1: Change Database status to Read-Write

USE [master]
GO
ALTER DATABASE [dbname] SET  READ_WRITE WITH NO_WAIT
GO

Step 2: Follow the blog post to create statistics from Read-Only Database How to Script Statistics from SSMS? – Scripting Statistics is Disabled in SSMS

Step 3: Execute the script generated from Step 2

Step 4: Change Database status to Read-Only

USE [master]
GO
ALTER DATABASE [dbname] SET  READ_ONLY WITH NO_WAIT
GO

Let me know what you think of this blog post series.

Reference: Pinal Dave (http://blog.sqlauthority.com)

SQL SERVER – Location of Statistics Before and After Database is Marked as a Read-Only

Earlier last week I wrote a blog post about Statistics for Read-Only Database are in TempDB, I received a very interesting comment from Ayman El-Ghazali on the same blog post. Let me reproduce the same comment over here.

“Nice post. What if you create a database, create some statistics in there, then later decide to switch it to Read-Only? How are those statistics updated if they exist inside the Read-Only DB? From your post I understood that all new statistics created will be in TempDB but what about the older stuff that resides in the DB that was switched to Read-Only?” (Original Comment)

In simple words what will happen to the statistics which were created before the database changed status to Read-Only.

Here is the answer – the statistics which were created before the database was marked as a read-only will still stay in the same database and it will be permanent statistics. However, all the new statistics which we will be creating after the database is marked as a read-only are created in the TempDB.

Let us validate the same with the help of demonstration:

In following script below we are creating the statistics before and after the database is marked as a read-only. We will check the status of the statistics location before and after the database is marked as a Read-Only.

-- Create Database
CREATE DATABASE [Read-Only]
GO
-- Use Database
USE [Read-Only]
GO
-- Create Table
CREATE TABLE [Shift](
[ShiftID] [tinyint] NOT NULL,
[Name] VARCHAR(100) NOT NULL,
[StartTime] [time](7) NOT NULL,
[EndTime] [time](7) NOT NULL,
[ModifiedDate] [datetime] NOT NULL
)
GO
-- Insert Table
INSERT [Shift] ([ShiftID], [Name], [StartTime], [EndTime], [ModifiedDate])
VALUES (1, N'Day', GETDATE(), GETDATE(), GETDATE())
GO
INSERT [Shift] ([ShiftID], [Name], [StartTime], [EndTime], [ModifiedDate])
VALUES (2, N'Evening', GETDATE(), GETDATE(), GETDATE())
GO
INSERT [Shift] ([ShiftID], [Name], [StartTime], [EndTime], [ModifiedDate])
VALUES (3, N'Night', GETDATE(), GETDATE(), GETDATE())
GO
-- Simple Select Statement to build statistics
-- BEFORE Database is Read Only
SELECT *
FROM [Shift]
WHERE Name = 'Day'
GO
-- Check if there are temporary statistics
SELECT OBJECT_NAME(OBJECT_ID) TableName, name, auto_created,
user_created, is_temporary
FROM   sys.stats
WHERE OBJECT_NAME(OBJECT_ID) = 'Shift'
GO
-- Make Database Read Only
ALTER DATABASE [Read-Only] SET READ_ONLY
GO
-- Check if there are temporary statistics
SELECT OBJECT_NAME(OBJECT_ID) TableName, name, auto_created,
user_created, is_temporary
FROM   sys.stats
WHERE OBJECT_NAME(OBJECT_ID) = 'Shift'
GO
-- Simple Select Statement to build statistics
-- AFTER Database is Read Only
SELECT *
FROM [Shift]
WHERE ShiftID = 1
GO
-- Check if there are temporary statistics
SELECT OBJECT_NAME(OBJECT_ID) TableName, name, auto_created,
user_created, is_temporary
FROM   sys.stats
WHERE OBJECT_NAME(OBJECT_ID) = 'Shift'
GO
-- Clean up
USE MASTER
GO
DROP DATABASE [Read-Only]
GO

Here is the result set explained with comments.

Let me know if you find this information interesting. Please note that this only applies to SQL Server 2012.

Reference: Pinal Dave (http://blog.sqlauthority.com)
