SQL SERVER – Difference Between Unique Index vs Unique Constraint

Unique Index and Unique Constraint are the same. They achieve same goal. SQL Performance is same for both.

Add Unique Constraint
ALTER TABLE dbo.<tablename> ADD CONSTRAINT
<namingconventionconstraint> UNIQUE NONCLUSTERED
(
<
columnname>
)
ON [PRIMARY]

Add Unique Index
CREATE UNIQUE NONCLUSTERED INDEX
<namingconventionconstraint> ON dbo.<tablename>
(
<
columnname>
)
ON [PRIMARY]

There is no difference between Unique Index and Unique Constraint. Even though syntax are different the effect is the same. Unique Constraint creates Unique Index to maintain the constraint to prevent duplicate keys. Unique Index or Primary Key Index are physical structure that maintain uniqueness over some combination of columns across all rows of a table. It is a convenient way to enforce a Unique Constraint for SQL Server.

Reference : Pinal Dave (https://blog.sqlauthority.com)

, ,
Previous Post
SQL SERVER – Enable xp_cmdshell using sp_configure
Next Post
SQL SERVER – SELECT vs. SET Performance Comparison

Related Posts

56 Comments. Leave new

  • Darshan shah
    June 9, 2008 5:17 pm

    Hi Pardeepe,

    U can define unique key on varchar datatype but u can’t do it on bit datatype bcz bit datatype has values 0,1,null .

    Reply
  • Tushar Parekh
    July 7, 2008 8:01 pm

    please explain how the value ‘a’ and ‘a ‘ are treated the same in SQL Server 2005 when creating indexes:

    create table a(b nvarchar(5))
    insert into a values (‘a’)
    insert into a values (‘a ‘) — please note space at the end
    create unique index a1 on a(b)

    gives error:

    Msg 1505, Level 16, State 1, Line 2
    The CREATE UNIQUE INDEX statement terminated because a duplicate key was found for the object name ‘dbo.a’ and the index name ‘a1’. The duplicate key value is (a ).

    Reply
  • Darshan,
    I’m afraid that is incorrect. A foreign key may reference the primary key of the table *or* any column(s) defined as unique.

    Tushar,
    In Sql Server, any trailing spaces are ignored when comparing strings. I assume this is so that if a field is defined “char(10)” and another is defined “varchar(10)” and you insert ‘a’ into each one, then CharField = VarCharField will evaluate to TRUE even though the char(10) field actually contains an ‘a’ followed by 9 spaces.

    So in statements like “where RTrim(CharField) = RTrim(VarCharField)”, the RTrim is not necessary. Even Len(CharField) and Len(VarCharField) will return 1 for both. However, leading spaces *are* significant.

    Reply
  • Tushar Parekh
    July 12, 2008 9:12 am

    TommCatt

    Thankx for your reply.

    Your explanation is correct.

    As mentioned by you, I am aware of SQL Server’s handling of various string data types.

    In my opinion, ignoring trailing blanks while comparing string objects (aspecially when they are defined as variable length strings is a bad design flow).

    I have designed a data warehouse where we are bringing data from Oracle whose table’s have key values e.g. AB and AB. Again having space in a key field itself is a bad design but structurally Oracle treats AB and AB as different values (which infact they are) and handles them OK.

    When I bring then over to SQL server, I get unique key violation … vola … :)

    My work around is to replace trailing blanks in key fields with ~ character. Again a temporary fix till SQL Server provides a way to have sound string data type comparisons.

    Again, Thankx for your reply.

    Reply
    • Tushar,

      Having same Oracle –> SQL Server conversion problem. Its only to be maintained for historical reporting so your work around is perfect!
      I tried ANSI_PADDING ON (at db level and at table create and insert time) but no luck and gave up.

      “My work around is to replace trailing blanks in key fields with ~ character. Again a temporary fix till SQL Server provides a way to have sound string data type comparisons”

      A container to hold 6 beers at the same time! BRILLIANT!!

      THX
      FC Wright

      Reply
  • i need to know how work when there is a situation that there is a Unique Key and this field “alow null”, but when i am going to create a Unique Key the SQLSERVER saw that there were values duplicated and the values are “nulls”. How do i sove this problem?

    Reply
  • @Cristiano,

    As you may be aware, Unique Key can allow only one null. Meaning only one null can be accepted not more than that. If you have more than one null on any column, you cannot make that column/field as unique key.

    I am sure there must be another way of doing this, I would do something like this,

    1. Since there is no way you can make that field a unique key, how about making a composite key.

    a) Combine this field with any other unique column/field and make a composite unique key. If any other unique key already exists then add this field to the previous unique key.

    b) if you do not have any unique key ( I am sure you do), but if you dont, then you can do this always, using Enterprise manager or SSMS object Explorer, create a new Identity column in the table and then create a unique composite key on these two field. ( You can create an identity column if you have data in the table, you DONT have to drop and recreate the table, using EM or SSMS you can always create a identity column in the table).

    If you consider case a), then make sure there are no duplicates for the combination of new field and the field you chose for unique key.

    If you create a composite unique key on cola and colb combined then you can have more than one null in cola and in colb, but again the combination of cola and colb should be unique.

    Once you start making a composite unique key… this concept will be more easier.

    Try doing this, either in Enterprise Manager or SSMS ( Object Explorer) much easier in interface than executing scripts.

    Hope this helps.
    Imran.

    Reply
  • Just discovered another difference between declaring a unique index vs. a unique constraint.

    SQL will raise an error with an error code of 2601 when violating a unique index, while it will use error code 2627 for violating a unique constraint.

    Minor difference, but while they are very similar, they are NOT the same.

    Reply
  • Brian Tkatch
    June 17, 2009 5:02 pm

    @Reed

    Very interesting!

    CREATE TABLE A(A INT UNIQUE);
    INSERT INTO A(A) VALUES(1);
    INSERT INTO A(A) VALUES(1);
    DROP TABLE A;

    CREATE TABLE A(A INT);
    CREATE UNIQUE INDEX AA ON A(A);
    INSERT INTO A(A) VALUES(1);
    INSERT INTO A(A) VALUES(1);
    DROP TABLE A;

    Reply
  • Love this site!!

    Reply
  • How retrieve “Unique Constraints” and “Unique Index” from database using SQL?

    thanks

    Reply
    • José Américo Antoine Jr
      July 30, 2010 3:28 am

      I think you can’t obtain these values direct from sql server, probably you can do using the system tables.
      I did this in .net C# via OLEDB
      Above the code:

      using System;
      using System.Collections;
      using System.Data;
      using System.Data.OleDb;

      namespace namespace_name {
      public class class_name {
      private string table_name = “tabela_teste”;
      private string var_OleDbConnection = “Provider=sqloledb;Data Source=127.0.0.1;Initial Catalog=database_name;User Id=sa;Password=;”;
      #region public indices_colunas[] indexes
      private indexes_columns[] Indices;
      public indexes_columns[] indexes {
      get {
      if (Indices == null) {
      ArrayList ar = new ArrayList();
      DataView dv = GetOleDbSchema(System.Data.OleDb.OleDbSchemaGuid.Indexes, new object[] {null, null, null});
      for (int i = 0; i < dv.Count; i++) {
      if (dv[i]["TABLE_NAME"].ToString().Trim().ToLower() == table_name.ToLower()) {
      if (dv[i]["TABLE_NAME"].ToString().Trim().ToLower() == table_name.ToLower()) {
      indexes_columns ind = new indexes_columns();
      ind.table_name = dv[i]["TABLE_NAME"].ToString();
      ind.column_name = dv[i]["COLUMN_NAME"].ToString();
      ind.index_name = dv[i]["INDEX_NAME"].ToString();
      ind.primary_key = Convert.ToBoolean(dv[i]["PRIMARY_KEY"]);
      ind.clustered = Convert.ToBoolean(dv[i]["CLUSTERED"]);
      ind.unique = Convert.ToBoolean(dv[i]["UNIQUE"]);
      ar.Add(ind);
      }
      }
      }
      Indices = new indexes_columns[ar.Count];
      ar.CopyTo((indexes_columns[]) Indices);
      }
      return Indices;
      }
      }
      #endregion
      #region public struct indexes_columns
      public struct indexes_columns {
      public string table_name;
      public string column_name;
      public bool clustered;
      public bool unique;
      public bool primary_key;
      public string index_name;

      }
      #endregion
      private DataView GetOleDbSchema(Guid SchemaGuid, object[] parametros) {
      DataView dv = new DataView();
      OleDbConnection myConnection = new OleDbConnection(var_OleDbConnection);
      try {
      myConnection.Open();
      dv = new DataView(myConnection.GetOleDbSchemaTable(SchemaGuid, parametros));
      }
      catch {
      throw;
      }
      finally {
      myConnection.Close();
      }
      return dv;
      }
      }
      }

      Reply
    • Igor Krupitsky
      August 6, 2010 7:40 pm

      To retrieve “Unique Constraints” :
      sp_helpconstraint MyTable,’nomsg’

      To retrieve “Unique Index”:
      select name, type_desc, is_unique, is_primary_key
      from sys.indexes
      where object_id = object_id(‘MyTable’)

      Igor

      Reply
  • Fabio Franco
    April 6, 2011 2:29 am

    Additional information here:

    Reply
  • Hi i need a table as follows

    ID, Accno, Type
    1 , 1 , 1
    1 , 1, 2
    1, 1, 3
    1 , 2 , 1 it can not be allowed
    2 , 1, 1 it can be allowed
    how can i create this type of table?
    ID cannot be used for any Other Account Number but it can be used multiple times for same Account Number??

    Thanks in advance
    Madhukumar N

    Reply
    • One possible way is to use make use of insert trigger and check this

      Reply
    • CREATE TABLE dbo.Madhu(
      ID int NOT NULL,
      AccNo int NOT NULL,
      Type int NOT NULL,
      PRIMARY KEY (ID,AccNo,Type));

      go

      CREATE VIEW dbo.MadhoIDAccNo WITH SCHEMABINDING AS
      SELECT ID, AccNo, COUNT_BIG(*) c
      FROM dbo.Madhu
      GROUP BY ID, AccNo;

      go

      CREATE UNIQUE CLUSTERED INDEX OnlyOneAccNoPerID ON dbo.MadhoIDAccNo(ID);

      Reply
  • A.M. de Jong
    May 19, 2011 1:21 pm

    You can Include a column in a (Unique) Index. Although this extra column (p.e. a primary key) can always make this index Unique it does not affect the uniqueness of the other columns.
    So If you have a identity seed table with a PK on the ID and you create a Unique Index on column 2 and 3 and INCLUDe the PK column in the index duplicate values of column 2 & 3 will still be noticed (the inserts fails or when IGNORE_DUP_KEY = ON it is ignored)

    Reply
  • I haven’t tried any of this yet,but it seems that another difference between a unique index and a unique constraint would be the ability to use the optional INCLUDE clause as part of the CREATE INDEX statement to include columns that are not part of the actual unique index. It would probably be overkill, but it seems that you could have both a unique index and a unique constraint and thereby get the benefits of both.

    Reply
    • DHall | August 31, 2011 at 11:50 pm
      I tried!
      And it seems to be a really difference. On 2008R2 at least.

      Reply
  • Cannot connect to sql server 2005 management studio express on local pc using windows authentication? & SQL Configuration tool is also not available with my setup…
    cannot connect to sql server 2005 management studio express on local pc using windows authentication?
    It’s unable connect to SQL server 2005 management studio express on local m/c using windows authentication. I went through microsoft support script but it also cann’t wok as there is no configuration manager installed with setup (43.2 MB). If there is pb in setup files or something else….
    while connection it shows error report is as Follows

    TITLE: Connect to Server
    ——————————

    Cannot connect to pran-pun-srv-trup.

    ——————————
    ADDITIONAL INFORMATION:

    An error has occurred while establishing a connection to the server. When connecting to SQL Server 2005, this failure may be caused by the fact that under the default settings SQL Server does not allow remote connections. (provider: Named Pipes Provider, error: 40 – Could not open a connection to SQL Server) (Microsoft SQL Server, Error: 2)

    Reply
  • Great! Help

    Reply
  • RAM……
    Can We have more than one Unique Constraints on the Same Column

    Reply
  • mercedeh.sh@gmail.com
    August 14, 2012 5:28 pm

    thanks dear friend for usefull learning

    Reply
  • There are differences in the DROP statements as well:

    — UNIQUE CONSTRAINT
    ALTER TABLE DROP CONSTRAINT

    — UNIQUE INDEX
    DROP INDEX ON

    Reply
    • Paw Jershauge
      August 1, 2013 1:27 pm

      The reason for this is that UNIQUE constraint is a database object. UNIQUE index is not a database object. ;)

      Reply
  • short and clear please keep it up. is there any way to create some other constraint using sql server UI

    Reply
