SQL SERVER – Transfer The Logins and The Passwords Between Instances of SQL Server 2005

This question was asked to me by one of reader.

“I just upgraded my server with better hardware and newer operating system. How can I transfer the logins and the passwords between two of my SQL Server?”

I think Microsoft has wonderful documentation for this issue. kb 918992

I will briefly describe the solution here :
Run the script in Query Editor. It will generate the script of username and password in the windows.
USE master
GO
IF OBJECT_ID ('sp_hexadecimal') IS NOT NULL
DROP PROCEDURE sp_hexadecimal
GO
CREATE PROCEDURE sp_hexadecimal
@binvalue varbinary(256),
@hexvalue varchar(256) OUTPUT
AS
DECLARE
@charvalue varchar(256)
DECLARE @i int
DECLARE
@length int
DECLARE
@hexstring char(16)
SELECT @charvalue = '0x'
SELECT @i = 1
SELECT @length = DATALENGTH (@binvalue)
SELECT @hexstring = '0123456789ABCDEF'
WHILE (@i <= @length)
BEGIN
DECLARE
@tempint int
DECLARE
@firstint int
DECLARE
@secondint int
SELECT
@tempint = CONVERT(int, SUBSTRING(@binvalue,@i,1))
SELECT @firstint = FLOOR(@tempint/16)
SELECT @secondint = @tempint - (@firstint*16)
SELECT @charvalue = @charvalue +
SUBSTRING(@hexstring, @firstint+1, 1) +
SUBSTRING(@hexstring, @secondint+1, 1)
SELECT @i = @i + 1
END
SELECT
@hexvalue = @charvalue
GO
IF OBJECT_ID ('sp_help_revlogin') IS NOT NULL
DROP PROCEDURE sp_help_revlogin
GO
CREATE PROCEDURE sp_help_revlogin @login_name sysname = NULL AS
DECLARE
@name sysname
DECLARE @xstatus int
DECLARE
@binpwd varbinary (256)
DECLARE @txtpwd sysname
DECLARE @tmpstr varchar (256)
DECLARE @SID_varbinary varbinary(85)
DECLARE @SID_string varchar(256)
IF (@login_name IS NULL)
DECLARE login_curs CURSOR FOR
SELECT
sid, name, xstatus, password
FROM master..sysxlogins
WHERE srvid IS NULL
AND
name <> 'sa'
ELSE
DECLARE
login_curs CURSOR FOR
SELECT
sid, name, xstatus, password
FROM master..sysxlogins
WHERE srvid IS NULL
AND
name = @login_name
OPEN login_curs
FETCH NEXT
FROM login_curs INTO @SID_varbinary, @name, @xstatus, @binpwd
IF (@@fetch_status = -1)
BEGIN
PRINT
'No login(s) found.'
CLOSE login_curs
DEALLOCATE login_curs
RETURN -1
END
SET
@tmpstr = '/* sp_help_revlogin script '
PRINT @tmpstr
SET @tmpstr = '** Generated '
+ CONVERT (varchar, GETDATE()) + ' on ' + @@SERVERNAME + ' */'
PRINT @tmpstr
PRINT ''
PRINT 'DECLARE @pwd sysname'
WHILE (@@fetch_status <> -1)
BEGIN
IF
(@@fetch_status <> -2)
BEGIN
PRINT
''
SET @tmpstr = '-- Login: ' + @name
PRINT @tmpstr
IF (@xstatus & 4) = 4
BEGIN -- NT authenticated account/group
IF (@xstatus & 1) = 1
BEGIN -- NT login is denied access
SET @tmpstr = 'EXEC master..sp_denylogin ''' + @name + ''''
PRINT @tmpstr
END
ELSE
BEGIN
-- NT login has access
SET @tmpstr = 'EXEC master..sp_grantlogin ''' + @name + ''''
PRINT @tmpstr
END
END
ELSE
BEGIN
-- SQL Server authentication
IF (@binpwd IS NOT NULL)
BEGIN -- Non-null password
EXEC sp_hexadecimal @binpwd, @txtpwd OUT
IF (@xstatus & 2048) = 2048
SET @tmpstr = 'SET @pwd = CONVERT (varchar(256), ' + @txtpwd + ')'
ELSE
SET
@tmpstr = 'SET @pwd = CONVERT (varbinary(256), ' + @txtpwd + ')'
PRINT @tmpstr
EXEC sp_hexadecimal @SID_varbinary,@SID_string OUT
SET @tmpstr = 'EXEC master..sp_addlogin ''' + @name
+ ''', @pwd, @sid = ' + @SID_string + ', @encryptopt = '
END
ELSE
BEGIN
-- Null password
EXEC sp_hexadecimal @SID_varbinary,@SID_string OUT
SET @tmpstr = 'EXEC master..sp_addlogin ''' + @name
+ ''', NULL, @sid = ' + @SID_string + ', @encryptopt = '
END
IF
(@xstatus & 2048) = 2048
-- login upgraded from 6.5
SET @tmpstr = @tmpstr + '''skip_encryption_old'''
ELSE
SET
@tmpstr = @tmpstr + '''skip_encryption'''
PRINT @tmpstr
END
END
FETCH
NEXT
FROM login_curs INTO @SID_varbinary, @name, @xstatus, @binpwd
END
CLOSE
login_curs
DEALLOCATE login_curs
RETURN 0
GO
----- End Script -----
EXEC master..sp_help_revlogin
GO

Now copy the generated script and run it on other SQL Server where you want to move username and password. Make sure that you are logged with sysadmin role.

Reference : Pinal Dave (http://blog.SQLAuthority.com) , kb 918992
