SQL SERVER – Install Error: Microsoft Cluster Service (MSCS) Cluster Verification Errors – Part 3

In recent past, I was assisting a client in installing SQL Server clustered instance in a Windows Cluster. There were many errors encountered and I learned a lot from this experience. In this blog, we would learn about Microsoft Cluster Service (MSCS) cluster verification errors which might appear during installation or AddNode.

We got the below error and as we can see, it was a setup “rule” failure rather than an installation error.

SQL SERVER - Install Error: Microsoft Cluster Service (MSCS) Cluster Verification Errors - Part 3 clus-facet-p3-01-800x581

Setup wizard failed with the rule — Microsoft Cluster Service (MSCS) cluster verification errors. Once we have this error, we would not be able to proceed next unless we fix it or follow KB to skip this rule.

From the Detail.txt we found the below error:

<DateTime>Slp: Initializing rule : Microsoft Cluster Service (MSCS) cluster verification errors
<DateTime>Slp: Rule applied features : ALL
<DateTime>Slp: Rule is will be executed : True
<DateTime>Slp: Init rule target object: Microsoft.SqlServer.Configuration.Cluster.Rules.ClusterServiceFacet
<DateTime>Slp: Validation Report not found on Node1.
<DateTime>Slp: Validation Report not found on Node2.DomainName.com.
<DateTime>Slp: Rule ‘Cluster_VerifyForErrors’ detection result: Is Cluster Online Results = True; Is Cluster Verfication complete = False; Verfication Has Warnings = False; Verification Has Errors = False; on Machine Node1
<DateTime>Slp: Evaluating rule : Cluster_VerifyForErrors
<DateTime>Slp: Rule running on machine: Node1
<DateTime>Slp: Rule evaluation done : Failed
<DateTime>Slp: Rule evaluation message: The cluster either has not been verified or there are errors or failures in the verification report. Refer to KB953748 or SQL Server Books Online for more information.

<DateTime>Slp: Send result to channel : RulesEngineNotificationChannel
<DateTime>Slp: Initializing rule : Microsoft Cluster Service (MSCS) cluster verification warnings
<DateTime>Slp: Rule applied features : ALL
<DateTime>Slp: Rule is will be executed : True
<DateTime>Slp: Init rule target object: Microsoft.SqlServer.Configuration.Cluster.Rules.ClusterServiceFacet
<DateTime>Slp: Validation Report not found on Node1.
<DateTime>Slp: Validation Report not found on Node2.DomainName.com.
<DateTime>Slp: Rule ‘Cluster_VerifyForWarnings’ detection result: Is Cluster Online Results = True; Is Cluster Verfication complete = False; Verfication Has Warnings = False; Verification Has Errors = False; on Machine Node1
<DateTime>Slp: Evaluating rule : Cluster_VerifyForWarnings
<DateTime>Slp: Rule running on machine: Node1
<DateTime>Slp: Rule evaluation done : Warning
<DateTime>Slp: Rule evaluation message: The MSCS cluster has been validated but there are warnings in the MSCS cluster validation report, or some tests were skipped while running the validatation. To continue, run validation from the Windows Cluster Administration tool to ensure that the MSCS cluster validation has been run and that the MSCS cluster validation report does not contain errors.

We had discussed a few issues in Part 1 and Part 2 of this blog and you can find it here

Today we will discuss another scenario which produces the same error, but the solution is different.

Unable to find the Cluster Validation report:

If the respective file is not found in the given location, we would see it clearly mentioned in Detail.txt file as shown below:

<DateTime>Slp: Validation Report not found on Node1.DomainName.com
<DateTime>Slp: Validation Report not found on Node2.DomainName.com

If you use one of my favorite tool and a procmon trace and you will notice entries like below. The user might have deleted/moved the given file. The report is usually located under – C:\Windows\Cluster\Reports

<DateTime>
setup1xx.exe
7212 CreateFile
\\Node1.Domain.com\admin$\Cluster\Reports\Validation Data For Node Set 9431D731EF6810180D4000D550DDB48DD960F349.xml
NAME NOT FOUND

SOLUTION/WORKAROUND

Open the cluster validation report to check the results. If there are no errors found, just rename the file to the name found in the procmon (Validation Data For Node Set 9431D731EF6810180D4000D550DDB48DD960F349.xml). else re-run Windows Cluster validation to generate a new report and this new report will be used by the setup the next time when it runs.

I have written three blogs in the same series as I found multiple reasons for such behavior. Please comment and let me know if you found some more causes and ways to fix it.

Reference: Pinal Dave (https://blog.sqlauthority.com)

, , ,
Previous Post
SQL SERVER – Unable to Run Maintenance Plan. Error: Integration Services Evaluation Period has Expired
Next Post
SQL SERVER – Transfer Logins Error: Msg 15021: Invalid Value Given for Parameter Password

Related Posts

1 Comment. Leave new

  • Chandru Maruthappan
    March 27, 2020 10:16 pm

    Thanks Pinal, After regenerate the cluster report, it’s fixed..
