Previously I wrote about SQL SERVER – 2008 – Introduction to SPARSE Columns. Let us understand the concept of SPARSE column in more detail. I suggest you read the first part before continuing reading this article.
All SPARSE columns are stored as one XML column in database. Let us see some of the advantage and disadvantage of SPARSE column.
Advantages of SPARSE column are:
- INSERT, UPDATE, and DELETE statements can reference the sparse columns by name. SPARSE column can work as one XML column as well.
- SPARSE column can take advantage of filtered Indexes, where data are filled in the row.
- SPARSE column saves lots of database space when there are zero or null values in database.
Disadvantages of SPARSE column are:
- SPARSE column does not have IDENTITY or ROWGUIDCOL property.
- SPARSE column can not be applied on text, ntext, image, timestamp, geometry, geography or user defined datatypes.
- SPARSE column can not have default value or rule or computed column.
- Clustered index or a unique primary key index can not be applied SPARSE column. SPARSE column can not be part of clustered index key.
- Table containing SPARSE column can have maximum size of 8018 bytes instead of regular 8060 bytes.
- A table operation which involves SPARSE column takes performance hit over regular column.
Let me know your thoughts about SPARSE column feature of SQL Server 2008, I am very eager to see your point of view on this new feature.
Reference : Pinal Dave (https://blog.sqlauthority.com)
27 Comments. Leave new
SPARSE column can not have default value or rule or computed column.
Only this thing looks odd.Other things are not that much problem
Sorry if this is a naive point!
Now we have the final release of SQl 2008, I have been trying to create a table with more that 1024 columns. I cannot. Even if all columns are defined as ‘int sparse’ I still get a max 1024 col error message.
Any advice would be very welcome.
Hello, Richard
In order to create more than 1024 columns, you have to have a columnset column defined in the table. We explict request this because the client can not retrieve more than 1024 columns, and we do not want people facing the issue of not being to retrieving data. Once the table has columnset defined, the select * will hide all sparse columns, and only see the column set. Neanwhile, people can still select individual sparse columns in their query. The default value of sparse column is NUll, that is the reason why we can not have default or rule on the column
So I’ve created my wide table and I need to import a comma delimited file…and for the life of me, I cannot get it to import.
I’ve used the import wizard (didn’t expect that to work) and bulk insert, all to no avail.
Is there a trick to this?
if you create a wide table (i.e., a table with column set). The default in/out method will only show the column set and hidden all sparse columns. If you want to import using the sparse columns, you may need to create a customized format file. Please refer the bcp format file for details.
The maximum number of supported sparse columns in a table is 30000 only but not 100000 in SQL Server 2008
create table mytable(sn int SPARSE null)
declare @SN int
set @SN=1
while(@SN<=1030)
begin
declare @CLN varchar(100)
set @CLN='Column' + convert(varchar(100),@SN)
declare @Query varchar(max)
set @Query='ALTER TABLE mytable ADD ' + @CLN + ' nvarchar(100) SPARSE'
set @SN=@SN+1
exec(@query)
end
Showing Erro:-
Msg 1702, Level 16, State 1, Line 1
CREATE TABLE failed because column 'Column1024' in table 'mytable' exceeds the maximum of 1024 columns.
Then how to create more then 1024 columns..????
Kulbhushan -The column count limit without the use of a column set is the same for sparse columns as it is for non-sparse columns = 1024
I think you didn’t get complete usage of SPARSE column.
Try this
create table mytable(sn int SPARSE null, AllDetails XML COLUMN_SET FOR ALL_SPARSE_COLUMNS)
declare @SN int
set @SN=1
while(@SN<=1030)
begin
declare @CLN varchar(100)
set @CLN='Column' + convert(varchar(100),@SN)
declare @Query varchar(max)
set @Query='ALTER TABLE mytable ADD ' + @CLN + ' nvarchar(100) SPARSE'
set @SN=@SN+1
exec(@query)
end
“A table operation which involves SPARSE column takes performance hit over regular column”
Can you elaborate on what you mean by above? How severe is the performance impact?
Great explanation as ever Pinal, have linked you from my blog.
r
Gan – it has to scan/parse the SPARSE column’s XML to find the field and extract it.
Can you be more specific when you say that rows containing sparse columns take a performance hit? Any metrics?
@mike, Honestly, I think it’s going to depend on a whole lot of things. Average size of the XML column that houses them all, but most importantly whether it’s part of any of the search arguments. If it’s just in the returned set I think you’re fine, but I wouldn’t use it if it’s in the WHERE clause.
Sparse columns are incompatible with data compression. Therefore sparse columns cannot be added to compressed tables, nor can any tables containing sparse columns be compressed.
@Reference MSDN : “http://msdn.microsoft.com/en-us/library/cc280604.aspx”
Sparse columns brokes cursor statements. Until you restart your database server !.
Someone should write this issue in “Restrictions for Using Sparse Columns” section on MSDN library.
Ytalo, that’s a bug. Open a case with MS. Can you elaborate on what happened?
Maybe I’m sleepy, but I don’t understand this at all:
“Clustered index or a unique primary key index can not be applied SPARSE column. SPARSE column can not be part of clustered index key.”
What is a “clustered index key”? Do you mean a clustered index that supports a key? But the first sentence already says a SPARSE column cannot have a clustered index placed on it. Or do you mean that a column that is part of a key which is supported by a clustered index cannot be SPARSE? BOL just says:
“A sparse column cannot be part of a clustered index or a unique primary key index.”
Is what you’re saying the same thing? Or something different? Thanks.
Hi ,
I tried with the below statement i.e Inserted not null and null values alternatively . The table with sparse columns takes more space than tables having unsparced columns. Any idea on this behavior ?
CREATE TABLE UnSparsed(ID INT IDENTITY(1,1),
FirstCol INT,
SecondCol VARCHAR(100),
ThirdCol SmallDateTime)
GO
CREATE TABLE Sparsed(ID INT IDENTITY(1,1),
FirstCol INT SPARSE,
SecondCol VARCHAR(100) SPARSE,
ThirdCol SmallDateTime SPARSE)
GO
DECLARE @idx INT = 0
DECLARE @FirstCol INT,
@SecondCol VARCHAR(100),
@ThirdCol SmallDateTime
WHILE @idx < 150000
BEGIN
Select @FirstCol = Case when @idx%2 = 0 Then 1000
Else Null End
Select @SecondCol = Case when @idx%2 = 0 Then 'Value'
Else Null End
Select @ThirdCol = Case when @idx%2 = 0 Then GETDATE()
Else Null End
INSERT INTO UnSparsed VALUES (@FirstCol,@SecondCol, @ThirdCol)
INSERT INTO Sparsed VALUES (@FirstCol, @SecondCol, @ThirdCol)
SET @idx+=1
END
GO
sp_spaceused 'UnSparsed'
GO
sp_spaceused 'Sparsed'
GO
DROP TABLE UnSparsed
GO
DROP TABLE Sparsed
GO
Here are the results
name rows reserved data index_size unused
UnSparsed 150000 4040 KB 3976 KB 8 KB 56 KB
name rows reserved data index_size unused
Sparsed 150000 4616 KB 4584 KB 8 KB 24 KB
Ganesan, it’s all about ratios and percentages. Here’s the formula I came up with, based on trial and error. Yours isn’t a good test, since you always have the same length, and the ratio is 50%. Remember that the overhead is an extra 2 bytes for each field.
Standard
=(Number_Of_Rows*(Average_Varchar_Length+2)
*((100-Percent_Null)/100))
+(Number_Of_Rows*(Percent_Null/100*2))
Sparse:
=(Number_Of_Rows*(Average_Varchar_Length+4))*((100-Percent_Null)/100)
since SQL Server 2005 and up the 8060 bytes row limit does not apply for varchar, nvarchar, varbinary, sql_variant, CLR, varchar(max), nvarchar(max), varbinary(max), text, image, or xml columns
https://docs.microsoft.com/en-us/previous-versions/sql/sql-server-2005/ms186981(v=sql.90)
sir i wanted to know the max limit for number of column in single table of sql??????
Its not simple as it appears to me, I tried it on my user table with 1000000 records but with no benefit although middlename column, featured column have more than 800000 null records(middlename, parentid ). Here is the details of how I did it. Am I not doing it correctly or missing somewhere, Please suggest if anyone has really used it in practise.
Thanks.
select top 400000 * into user_with_sparse from dbo.users
select top 400000 * into user_without_sparse from dbo.users
ALTER TABLE user_with_sparse ALTER COLUMN middlename varchar(40) SPARSE NULL
ALTER TABLE user_with_sparse ALTER COLUMN Featured smallint SPARSE NULL
sp_spaceused ‘user_with_sparse’
user_with_sparse 400000 377120 KB 377032 KB 16 KB 72 KB
sp_spaceused ‘user_without_sparse’
user_without_sparse 400000 375280 KB 375184 KB 16 KB 80 KB
