SQL SERVER – Database Size Limitation in SQL Express

express SQL SERVER   Database Size Limitation in SQL ExpressI have a tendency to write a number of interview style questions and those are quite popular in this blog. Having said that, sometimes we get asked about tricky questions on a small variety which we might know some of the basics – but sometimes it makes us think twice. This blog is an inspiration on someone who quizzed me with a number of questions on SQL Server Express Edition and I thought to put them up here in a FAQ style for reference.

We all know that there is a limit in SQL Server Express Edition with respect to the size of the database. There have been many confusions around this area. This blog post is meant to come clear of those doubts – by no means this is not exhaustive of all. I have kept them in Q&A format and would add more.

  1. What is the size limit you are talking about in SQL Server Express Edition?

That is a function of  the version of SQL Server:
SQL 2000 Desktop Engine (MSDE) has limit of 2 GB data file(s) size.

SQL 2005 Express Edition has limit of 4 GB data file(s) size.

SQL 2008, SQL 2008 R2, SQL 2012 and SQL 2014 Express Edition has limit of 10 GB data file(s) size.

  1. What is the error I would get if I cross that the limits of data sizes mentioned above?

You are likely to face errors in that scenario. Here are two common errors for reference:
CREATE DATABASE or ALTER DATABASE failed because the resulting cumulative database size would exceed your licensed limit of 10240 MB per database

Size in the error message would depend on limit of that SQL Version of Express. The above message is from SQL 2008 R2 till SQL 2014.

In ERRORLOG, you would see errors as below when limit is reached.
Could not allocate space for object ‘TableName’.’IndexName’ in database ‘DatabaseName’ because the ‘PRIMARY’ filegroup is full. Create disk space by deleting unneeded files, dropping objects in the filegroup, adding additional files to the filegroup, or setting autogrowth on for existing files in the filegroup.

  1. Is this limit on size for per instance or per database?

The size limit is per database so if the database is composed of multiple data files, then the limit is across all data files in the single database.

  1. Can I have 2 databases of 10 GB each in SQL Server 2014?

Yes. As explained in #3 its per database data file limit.

  1. Does this limit include Transaction Log (LDF) file?

No. It’s only for data files.

  1. Does this limit include File stream file container?

No. It’s only for data files.

  1. Is there any workaround to increase the limit?

There is none to increase the file size limitation. Filestream is not part of the limit so is possible move the blob data file stream.

  1. Will my database be unusable?

No. Adding new data, which needs file size increase would fail with the error mentioned above. SELECT can still run on the database.

  1. What if I want to upgrade to full version of SQL from SQL Express?

That can be done using “Edition Upgrade” Below talks about EVAL edition but same steps can be applied for SQL Express upgrade also.

SQL SERVER – Evaluation Period Has Expired – How to Activate SQL Server?

  1. What else can be done?

Delete unwanted data and shrink the data file.

These are some of the common questions I have seen around with SQL Server Express Edition and its file size limits. Do let me know if you wanted to know anything specific in this area with Express Editions. Will be more than happy to expand the FAQ list to include them. Drop in a line via comments.

Reference: Pinal Dave (http://blog.sqlauthority.com)

SQL SERVER – Dedicated Access Control for SQL Server Express Edition – An error occurred while obtaining the dedicated administrator connection (DAC) port.

Recently I had faced very interesting situation. Due to some reason we were not able to login into the production server for one of client. The reason for the same was that server was very busy, we had to login into the system and bring server to normal situation. When all the attempts failed, I decided to login using Dedicated Administrator Connection (DAC). However when I attempted to connect using DAC it threw following error for me.

expressstart0 SQL SERVER   Dedicated Access Control for SQL Server Express Edition   An error occurred while obtaining the dedicated administrator connection (DAC) port.

C:\Users\pinald>sqlcmd -A -d master -S .\SQLEXPRESS

Sqlcmd: Error: Microsoft SQL Server Native Client 11.0 : SQL Server Network Interfaces: An error occurred while obtaining the dedicated administrator connection (DAC) port. Make sure that SQL Browser is running, or check the error log for t he port number [xFFFFFFFF]. .Sqlcmd: Error: Microsoft SQL Server Native Client 11.0 : Login timeout expired.Sqlcmd: Error: Microsoft SQL Server Native Client 11.0 : A network-related or instance-specific error has occurred while establishing a connection to SQL Server. Server is not found or not accessible. Check if instance name is correct and if SQL Server is configured to allow remote connections. For more information see SQL Server Books Online.

I was bit taken a back as I knew that my commands are correct to login and if DAC does not work, there should be some serious reason for it. When inquired further about the SQL Server version I learned that it was SQL Server Express version deployed. To conserve resources, SQL Server Express does not listen on the DAC port. There is an additional step to be done if SQL Server Express has to be used with DAC. Enable TRACEFLAG on SQL Server Express will enable the connection by DAC possible. Here is the quick methods how one can enable DAC on SQL Server Express.

Go to Start >> All Program >>Microsoft SQL Server (your version) >> Configuration Tools >> SQL Server Configuration Manager.

expressstart00 SQL SERVER   Dedicated Access Control for SQL Server Express Edition   An error occurred while obtaining the dedicated administrator connection (DAC) port.

Click on SQL Server Services >> Select your SQL Server Express version >> Right Click Properties >> select Startup Parameters

expressstart1 SQL SERVER   Dedicated Access Control for SQL Server Express Edition   An error occurred while obtaining the dedicated administrator connection (DAC) port.

Once on the Startup Parameter add the Startup parameter which is TRACEFLAG -T7806. Click on OK and RESTART SQL Server Express edition. Now once again try to connect to SQL Server Express edition and it will work just fine.

expressstart3 SQL SERVER   Dedicated Access Control for SQL Server Express Edition   An error occurred while obtaining the dedicated administrator connection (DAC) port.

This is absolutely documented method on BOL and SQL Server Express needs to be restarted.

Watch SQL in Sixty Seconds video to Resolve Connection Error:

Reference: Pinal Dave (http://blog.SQLAuthority.com)

SQLAuthority News – Download SQL Server 2008 Express Datasheet

Microsoft® SQL Server® 2008 Express is a free edition of SQL Server ideal for learning, developing and powering desktop and small server applications and for redistribution by ISVs.

Download SQL Server 2008 Express Datasheet

Abstract courtesy : Microsoft

Reference: Pinal Dave (http://blog.SQLAuthority.com)

SQL SERVER – Download FREE SQL SERVER Express Edition and Service Pack 1

Here is the quick link from where SQL Server 2008 Express Edition can be downloaded.

Download SQL Server 2008 Express Edition

You can download it with many additional details as described in following image. Click on above link to go to page and select desired version.

SQLExpress SQL SERVER   Download FREE SQL SERVER Express Edition and Service Pack 1

Additionally, please install SQL Server 2008 Express Service Pack 1.

You can read one of my previous article where I have covered SQL Server 2008 Express in detail SQL SERVER – SQL Server Express – A Complete Reference Guide.

Reference: Pinal Dave (http://blog.SQLAuthority.com)

SQL SERVER – Choose Right Edition of SQL Server Express for Your Application

SQL Server Express is better alternative of MySQL. I have recently helped quite a few organizations to move to SQL Server Express recently. However, one question keep on coming up quite often regarding which is the right edition for SQL Server Express. SQL Server Express have more than one edition available.

Here is the quick guide to select right edition for SQL Server.

After reading above guide if you are still not sure which edition you should select, leave a comment here or send me email and I will get back to you.

SQL Server 2008 Express with Advanced Services – 546.6 MB

  • SQL Server Database Engine
  • SQL Server Management Studio Basic
  • Full-Text Search
  • Reporting Services

SQL Server 2008 Express With Tools – 230.4 MB

  • SQL Server Database Engine
  • SQL Server Management Studio Basic

SQL Server 2008 Express Runtime Only – 82.5 MB

  • SQL Server Database Engine

SQL Server 2008 Express Management Studio Basic – 38.5 MB

  • SQL Server Management Studio Basic

SQL Server 2008 Management Studio Express is also known as SSMSE.

You can refer my complete reference article SQL SERVER – SQL Server Express – A Complete Reference Guide.

Reference: Pinal Dave (http://blog.SQLAuthority.com)

SQL SERVER – SQL Server Express – A Complete Reference Guide

SQL Server Express is one of the most valuable products of Microsoft. Very often, I face many questions with regard to SQL Server Express. Today, we will be covering some of the most commonly asked questions.

Q: What is the cost of SQL Server Express?
A: SQL Server Express is a FREE product from Microsoft.

Q: Where can I find more details about SQL Server Express?
A: On official Microsoft Site: http://www.microsoft.com/express/sql/default.aspx

Q: Why should I use SQL Server Express when I have full version available?
A: Usually, I install only the license version product on my system. When I do not have to use all the features of SQL Server, I install SQL Server Express.

Q: What is the maximum size per database for SQL Server Express?
A: SQL Server Express supports a maximum size of 4 GB per database, which excludes all the log files. 4 GB is not a very large size; however, if database is properly designed and the tables are properly arranged in a separate database, this limitation can be resolved to a certain extent.

Q: Can MySQL be compared with SQL Server Express as both of them are free products?
A: Yes. Both are free and have their own space. However, thus far, I have never faced a situation wherein the task that can be accomplished by using MySQL is not accomplished by SQL Server Express.

Q: Does SQL Server have sufficient help available online?
A: Yes. There are so many online help resources available for SQL Server Express that user will find strongest community for any FREE product.

Let me give you quick list of the online help resources. Even though I took some time to build this reference list, I am sure that all of you will appreciate this and will share with others, which is worth the effort!

Overview

Getting Started

Installation

Quick Start

Misc

Blogs

Webcasts

Reference : Pinal Dave (http://blog.sqlauthority.com)

SQL SERVER – Fix : Error: 15372 Failed to generate a ser instance od SQL Server due to a failure in starting the process for the user instance. The connection will be closed

Just a day ago, I was installing SQL Server Express on backup computer. I only use this computer when I have something to experiment. While installing SQL Server Express I found following error in my error log which prevented successful installation to computer. It was difficult to initially understand the problem by itself, after some try and error I found the solution.

Error: 15372, Severity: 16, State: 1.
Failed to generate a ser instance od SQL Server due to a failure in starting the process for the user instance.  The connection will be closed.

Solution for this error is fairly simple.

Fix/Workaround/Solution:

For XP:
Delete the directory “c:\Documents and Settings\username\Local Settings\Application Data\Microsoft\Microsoft SQL Server Data\SQLEXPRESS “

For Vista:
Delete the directory “c:\Users\<username>\AppData\Local\Microsoft\Microsoft Sql Server Data\SQLEXPRESS”

Reboot the system.

Watch SQL in Sixty Seconds video to Resolve Connection Error:

Reference : Pinal Dave (http://blog.sqlauthority.com)


SQL SERVER – Difference Between SQL Server Compact Edition (CE) and SQL Server Express Edition

I often received question regarding what are difference between SQL Server Compact Edition (CE) and SQL Server Express Edition. In one line – SQL Server CE is for mobile application and embaded systems where as SQL Server Express Edition is limited feature light version of SQL Server Standard.

SQL Server Compact Edition SQL Server Express Edition
ClickOnce Deployment ClickOnce Deployment
Installed centrally with an MSI Installed centrally with an MSI
XML storage XML storage
Transact-SQL Transact-SQL
Subscriber for merge replication Subscriber for merge replication
Simple transactions Simple transactions
Database size support – 4GB Database size support – 4GB
Number of concurrent connections – 256 Number of concurrent connections – Unlimited
Privately installed, embedded, with the application
Non-admin installation option
Runs on Windows Mobile platform
Runs in-process with application
Data file storage on a network share
Support for different file extensions
Code free, document safe, file format
Remote Data Access (RDA)
ADO.NET Sync Framework
Subscriber for merge replication
Simple transactions
Runs as a service
Procedural T-SQL
Distributed transactions
Native XML, XQuery/QPath
Stored procedures, views, triggers
Role-based security

I am interested to know if my readers have used any of these servers what was the real life application for the same.

Reference : Pinal Dave (http://blog.SQLAuthority.com)

Source : http://blog.sqlauthority.com/2009/04/22/sql-server-difference-between-sql-server-compact-edition-ce-and-sql-server-express-edition

SQL SERVER – 2008 – Download Microsoft SQL Server 2008 Express with Tools Free

Note: Download Microsoft SQL Server 2008 Express with Tools Free by Microsoft

SQL Server 2008 Express Edition was much awaited version of SQL Server 2008. It is FREE and available to download from web.

Microsoft SQL Server 2008 Express with Tools (SQL Server 2008 Express) is a free, easy-to-use version of SQL Server Express that includes graphical management tools. SQL Server 2008 Express provides powerful and reliable data management tools and rich features, data protection, and fast performance. It is ideal for small server applications and local data stores.

SQL Server 2008 Express with Tools has all of the features in SQL Server 2008 Express, plus you can easily manage and administer SQL Server 2008 Express with a easy-to-use graphical management tool – SQL Server 2008 Management Studio Basic.

Free to download, free to deploy, and free to redistribute as an embedded part of an application, SQL Server 2008 Express with Tools is the fast and easy way to develop and manage data-driven applications.

Download Microsoft SQL Server 2008 Express with Tools Free

Abstract courtesy : Microsoft

Reference : Pinal Dave (http://blog.SQLAuthority.com)

SQLAuthority News – SQL Server Express 2008 Downloads

Microsoft SQL Server 2008 Express with Tools

Microsoft SQL Server 2008 Express with Tools (SQL Server 2008 Express) is a free, easy-to-use version of SQL Server Express that includes graphical management tools. SQL Server 2008 Express provides powerful and reliable data management tools and rich features, data protection, and fast performance. It is ideal for small server applications and local data stores.

Download Microsoft SQL Server 2008 Express with Tools

Microsoft SQL Server 2008 Express with Advanced Services

Microsoft SQL Server 2008 Express with Advanced Services (SQL Server 2008 Express) is a free, easy-to-use version of SQL Server Express that includes a graphical management tool and powerful features for reporting and advanced text-based searches. SQL Server 2008 Express provides powerful and reliable data management tools and rich features, data protection, and fast performance. It is ideal for small server applications and local data stores.

SQL Server 2008 Express with Advanced Services has all of the features in SQL Server 2008 Express, plus you can:

* Easily manage and administer SQL Server 2008 Express with a easy-to-use graphical management tool – SQL Server 2008 Management Studio Basic.

* Issue full-text queries against plain character-based data in SQL Server tables. Full-text queries can include words and phrases, or multiple forms of a word or phrase.

* Run SQL Server Reporting Services reports on local relational data.

Download Microsoft SQL Server 2008 Express with Advanced Services

Abstract courtesy : Microsoft

Reference : Pinal Dave (http://blog.SQLAuthority.com)
